Dudek Hadron Cabrio You are an experienced trike pilot, averaging several hundred flight hours a year. You can master a fast and agile canopy. You love playing low with slaloms, wing overs, foot dragging etc. Maybe you take part in high-level competitions or plan to beat some world record. If so, you are looking for a really fast and agile paraglider with perfect handling and little power requirements. It has to be turbulence-proof, so the reflex aerofoil is a must… The Hadron Cabrio is the answer!
The paraglider is dedicated for the frequent and experienced flyers, who have perfectly mastered the reflex gliders specifics.
Hadron Cabrio’s “reflexivity” is regulated, and the trimmer range has been widened. At 5,9 aspect ratio its 60 cells allow for fast inflation and perfect internal pressure distribution. Synthetic rods on its leading edge bring considerably better launch characteristics and stability at high speeds.
Compared to Nucleon WRC Cabrio 42, the Hadron Cabrio has smaller power demand, clearly visible by smaller sink when gliding with power off. Hadron demands more care especially in turbulence, yet still remains stable and safe. Landing is typical with no special traits but short steering range.
Hadron Cabrio as all our paragliders is produced entirely in Europe, at our Polish plant. Thus close monitoring of the entire complicated production process is possible. Hadron is cut exclusively with a recently purchased state-of-the-art laser cutter, under highest precision.
Complete paraglider kit you receive includes:
- MotoBag XX (backpack for tight canopy packing, without harness)
- DewBag (quickpack)
- Transport bag including compression strap.
- pouch with documents and repair kit (self-adhesive cloth, spare line)
- wind ribbon and windsock
- small gifts
Total worth of these additional parts amounts to some 200 Euros.
Colours
Technical data
Name / size | Hadron Cabrio 34 | Hadron Duo 34 (for comparison) |
Approval – ULM identification | yes | – |
Trimmer | yes | yes |
Speed system | no | yes |
Cell number | 60 | 59 |
Surface flat [m2] | 34 | 34 |
Surface projected [m2] | 29.68 | 29.68 |
Wingspan flat [m] | 14.16 | 14.16 |
Wingspan projected [m] | 11.62 | 11.62 |
Aspect ratio flat | 5.90 | 5.90 |
Aspect ratio projected | 4.55 | 4.55 |
Sink rate [m/s] | min = 1,3 + – 0,2m/s | |
Speed [km/h] | min= 32; trim = 42; max = 57 + – 3km/h | |
Lines length (incl. risers) [m] | 8.93 | 8.93 |
Total lines length [m] | 466.5 | 415.9 |
Take-off weight [kg] | 170-300 | 160-215 |
Max take-off weight – competition [kg] | 325 | |
Distance betwen risers [cm] | 60 | |
Paraglider weight [kg] | 8.5 | 8.1 |
Lines | Edelrid A-8000U: 050, 090; 7343: 090, 140, 190, 280, 420 | Edelrid A-8000U: 050, 090; 7343: 090, 140, 190, 280, 420 |
Cloth | DominicoTex 41 & 34g / Porcher Hard 40g / SR Scrim / SR Laminate 180g | DominicoTex 41 & 34g / Porcher Hard 40g / SR Scrim / SR Laminate 180g |
Available toggles:
- TCT (Triple Comfort Toggle) standard (basic)
- TCT (Triple Comfort Toggle) short
- SCT (Sport Comfort Toggle) standard
- SCT (Sport Comfort Toggle) short
Wings parameters
CATEGORY | PARAMOTORING;TANDEMTRIKE |
---|---|
PILOT | COMPETITION;SPORTT |
CANOPY FEATURES
LAUNCH COMFORT | |
---|---|
AGILITY | |
BRAKE OPERATION | |
REFLEX | |
REFLEX MODE | Adjustable |
SHAPE RIGIDITY | |
PASSIVE SAFETY | |
ACCELERATION TRIM / SPEED | 100% / 0% |
MINIMUM SPEED | |
MAXIMUM SPEED | |
CLASSIC COMPS | |
SLALOM COMPS | |
ECONOMY | |
POWERED THERMALLING |
CONSTRUCTION FEATURES
CELLS | 60 |
---|---|
ASPECT RATIO | 5.9 |
SN – SHARK NOSE | no |
LE2R – LEADING EDGE DOUBLE REINFORCEMENTS | no |
PR – PUSH & RELAX TECHNOLOGY | no |
DOA – DUDEK OPTIMIZED AIRFOIL | no |
DRA – DUDEK REFLEX AIRFOIL | yes |
CSG – CANOPY SHAPE GUARD | yes |
LT – LASER TECHNOLOGY | yes |
FET – FLEXI EDGE TECHNOLOGY | yes |
MR – MINI RIBS | no |
ACS – ACTIVE CLEANING SLOTS | yes |
2-LINER | no |
3-LINER | no |
VALVES | no |
RISERS FUNCTIONALITY
TOGGLES TYPE | TCT – Triple Comfort Toggle |
---|---|
EASY KEEPER | yes |
SL – SMART LOCK | no |
NAPS | no |
TR – TRIMMERS | yes |
SS – SPEED SYSTEM | no |
ALC+ – ALTERNATIVE STEERING SYSTEM + | no |
TST – TIP STEERING TOGGLE | yes |
2D – 2D STEERING SYSTEM | yes |
EASY LUNCH RISER | yes |
TCL – TIP CONTROL LINE | no |
AC – ACTIVE CONTROL B | no |
PA – POWER ATTACK SYSTEM | no |
ACC – ACTIVE CONTROL C | no |
ULM APPROVAL | yes |
Other
WARRANTY | 24 months |
---|---|
AEROCASCO | option |
